Viking AK495 Motor Speed Electric Gear Pump, 7.5hp, 2.5in NPT Ports

$7,801.05
SKU AK495-7.5HP

ITEM:  Viking AK495 Motor Speed Electric Gear Pump, 7.5hp, 2.5in NPT Ports

Downloads:

Catalog Section 1441

Technical Service Manual

Dimensional Cut Sheet

Quick Specs:

  • P/N:  AK495
  • Manufacturer:  Viking Pumps
  • Type:  Electric Gear Pump, Motor Speed
  • Size:  2.5" NPT Ports, inlet/outlet
  • Viton Elastomers
  • Internal relief valve set to 100psi
  • 7.5hp motor, 1150rpm, TEFC, 254TC
  • 230/460V, 3-ph, 60Hz

Description:

 Viking’s Motor Speed Product Line internal gear pumps represent a technological advance in the science of flow. Through new techniques of feeding the rotor and idler, Viking has achieved what was once considered impossible – high flow rates operating at motor speeds. The largest size (QS) operates at reduced speeds, but still faster than other pumps of similar displacement. Higher speeds mean greater value, with the ability to move more fluid with a smaller pump. It also enables close-coupling to a motor or gearmotor, which eliminates shaft misalignment and results in longer seal and bearing life by preventing wear due to misalignment.

Model NTP Ports Nominal Pump Rating (60hz) GPM Nominal Pump Rating (60hz) m3/h Maximum RPM Maximum Pressure PSI Maximum Pressure BAR
G495 1 8 1.8 1750 250 17
GG495 1 10 2.3 1750 250 17
H495 1.5 15 3.4 1750 250 17
HJ495 1.5 20 4.5 1750 250 17
HL495 1.5 30 6.8 1750 250 17
AS495 2.5 55 12 1750 250 17
AK495 2.5 85 19 1750 250 17
AL495 3 115 26 1750 250 17
